RCGF18-18-6 Juice Plastic Bottle Filling Machine Capacity 6000BPH
Description
RCGF washing, filling ,capping 3 in 1 unit is a new type equipment, which is designed based on years' usual practice and adopt the advanced technology, and absorb many clients' views. It meets the client's requirement about filling different bottle size through one set. The suspension card bottleneck is adopted to make changing the bottle size more convenient.
Advantages
1) Suspending bottle-neck clamping design make the bottle stable during the high-speed moving conditions. By changing a few parts, it can meet the need of production of different types of bottles easily.
2) The new generation of stainless steel grab is adopted and the grabs have no contact with the area above the bottle screw thread. Nozzles in the grab can guarantee the complete wash of the interior of the bottle.
3) The advanced gravity filling technology used in this machine makes the filling quick, steady and accurate.
4) Magnetic torque is used for screw capping, and the power of screw capping can be adjusted steplessly. Capping is reliable and do no harm to the caps.
5) Advanced technologies, such as human-machine interface touch-screen and PLC program control are adopted in this mineral water plant machine.
6) All parts that have direct contact with the water are made of high quality stainless steel. The critical electrical components are from famous international companies, such as Mitsubishi, Omron to name a few.
Technical specification
| Model | RCGF8-8-3 | RCGF12-12-4 | RCGF16-16-5 | RCGF18-18-6 | RCGF24-24-8 |
| Capacity 500ml | 2000BPH | 3000-4000BPH | 4000-6000BPH | 6000-8000BPH | 8000-12000BPH |
| Bottle type | Round or square PET bottle (we can design freely) |
| Bottle diameter | 50-115 mm |
| Bottle height | 160-320 mm |
| Air consumption | 0.3-0.7Mpa |
| Air pressure | 5-8bar |
| Washing medium | Aseptic water |
| Pressure of washing | >0.06Mpa <=0.2Mpa |
| Power (kw) | 3 | 4.4 | 4.4 | 4.4 | 5.2 |
| Weight (kg) | 3000 | 3200 | 4000 | 4500 | 6500 |
Electric configuration
| Transducer | Siemens |
| Touch screen | Siemens |
| PLC | Siemens |
| Stabilized voltage supply | Schneider |
| Contactor | Schneider |
| Approach switch | Schneider |
| Air switch | Schneider |
| Light sensor | Autonics |
| Motor | ABB |
Option machines
| Online cap washing system | Including: cap tunnel, stainless steel frame, washing head, two sets of washing pump and two sets of recycling tanks in stainless steel 304. |
| Cap elevator | Air consumption:0.3kg Air blower: 0.25kw Rotary: 2800rpm Power:0.18kw Rotary:1360rpm Machine size: 600*600*1800mm Weight:150kg |
After-sales service
| Shipping | Port of loading: Shanghai port Port of discharge: Basing on the destination Container: LCL or FCL |
| Installation and commissioning | We have technician to be overseas for machine setup and commissioning |
| Training | The Buyer should arrange workers who work on the production line to work with the Seller’s technician |
| Preparation | Sample bottle, cap, water and electricity shall be ready before technician arrives |
| Extra expense | Client should be responsible for the round-way flight tickets, local transportation, local hotel and eating; |
Detailed photo for ref
